Free Download EMX (Expert Moldbase Extentions) 16.0.2.1 for Creo 10.0.2+ | 327.3 mb
Owner:B&W Software
Product Name:Expert Moldbase Extension (EMX)
Version:16.0.2.1 for PTC Creo 10.0.2+
Supported Architectures:x64
Website Home Page :
Languages Supported:multilanguage
System Requirements:Windows *
Software Prerequisites:pre-installed PTC Creo 10.0.2+
Size:327.3 mb
Languages Supported: English, Deutsch
B&W Software, the leading global provider of add-on applications for the 3D-CAD System Creo Parametric, is pleased to announce the availability ofExpert Moldbase Extension (EMX) 16.0.2.1 for PTC Creo 10.0.2+. Use EMX to create a mold base as a regular assembly.
Changelog 16.0.2.1
Enhancements
- Add new HASCO Guide component: Z1300
- Add new HASCO Ejector Pins: DLC shouldered Z4430, cylindrical air-ventilated pin Z401
- Add new HASCO Top Interlocks: Cubic interlocks Z060 and Z080, spacer plate Z081.
- Add new HASCO Side Interlocks: Z085.
- Add new HASCO Attachment components: Flange Z167, Cycle Counter A5730, A5730HT, A57300, A57300HT, A5731, A5732
- Component Editor: Enhance functionality to enable editing of subcomponent instances dimensions. [RM-16954]
Improvements
- Introduce parameter EMX_EDGE_CHAMFER_IGNORE_FEATURE which allows to ignore edges from a certain feature for additional chamfer creation. [RM-16562]
- Update existing HASCO ejector pins, guides, locatings rings, screws, top interlocks data to state mid 2023.
- Introduce separate bore_cooling.cfg files for inch and mm. [RM-12618]
- Do not ceil length in ejector note with NR_DIGITS_BOM. Instead always use NR_DIGITS_COMMON. [RM-16394]
Bugfixes
- Issue fixed: Crash in Model Size Dialog in case use tries to select another model in Part Mode. [RM-16350]
PTC Creo EMXis an indispensable add-on tool for moldmakers and toolmakers that eliminates timeconsuming, tedious tasks and the need for data translation that typically slows down the product development process. PTC Creo EMX allows users to create moldbase layouts in a familiar 2D environment and automatically generate a 3D model to leverage the benefits of 3D design.
B&W Webinar "What's new in EMX?" in Creo Parametric
B&W Softwareis the leading global provider of add-on applications for the 3D-CAD System Creo Parametric. Since many years B&W develops specially tailored software solutions to increase efficiency in the field of product design.
Our partnerPTCis a leading provider of CAD, PLM and IoT Software solutions. Creo Parametric is the flagship solution for 3D CAD modeling and provides outstanding design capabilities for parts and assemblies. The widely established modules of this software portfolio (including some B&W applications) are installed at more than 28.000 enterprises worldwide and contribute to design and service advantages.
